Hioki LR8534 Wireless Logger Module for strain gauges

Hioki LR8534 - Wireless Logger Module for Voltage, 1 msec, 5 channels

5-channel wireless interface module for Hioki LR8450-01 Data Logger, update interval 1 ms, for strain gauges, 16 bits, 1/2/4-gauge method, AC or battery operation, spring-cage terminal block.

The Hioki LR8534 Wireless Strain Module is a 5-channel measurement module for the LR8450-01 Wireless Data Logger. Up to seven LR8534 modules can be connected to a single LR8450-01, allowing users to record and transfer data via wireless LAN of up to 35 channels in a single device. By combining the LR8450-01 with seven LR8534 and four U8554 plug-in modules, the total setup can be extended to up to 55 channels.

This module supports measurement of strain by using strain gauges or strain gauge transducers. Input signals are connected to the module through a spring-cage terminal block, providing a quick and secure, vibration-resistant connection.

The module allows measuring strain with the 1-gauge method – 2- or 3-wire setup. For applications requiring higher accuracies, the 2-gauge or 4-gauge methods can be used. The LR8534 module offers a fast update interval of 1 ms for all 5 channels simultaneously, making it ideal for dynamic and high-speed applications.

This wireless module comes with an AC adapter (Z1008) and a mounting plate with screws, allowing the module to be securely attached to a wall or other flat surface.

Features:

• Wireless data transmission to LR8450-01 Data Logger
• 5 input channels for strain gauges
• 1 ms update interval
• A/D resolution: 16 bits
• 1-gauge method (2-wire & 3-wire setup), 2-gauge method (adjacent sides), 4-gauge method
• Autonomous operation with wireless data transfer and battery option

Package Includes:

• LR8534 Wireless Strain Module
• Instruction manual
• Z3231 Wireless LAN Adapter
• Z1008 AC Adapter
• Mounting plate
• M3×4 screws (for use with mounting plate)
